2U Aluminium Louver Front; 5 x 3.5" Internal Drive Bays + 1 x 5.25" DVD Takes Various PSU's

Key Product Features:

  • 2U Rackmount Form Factor
  • 470mm Chassis Depth
  • 430mm Chassis Width
  • 44mm Chassis Height
  • Standard ATX PSU Compatibility
  • Micro ATX M/B Form Factor
  • 1 Fixed Bays - External - 5.25"
  • 5 Fixed Bays - Internal - 3.5"
  • 4 Low Profile PCI Expansion Slots
Product Code/SKU: SC-22470
2U Aluminium Louver Front; 5 x 3.5
Photo 1
Photo 2
Photo 3
Photo 4
Photo 5
Photo 6
Photo 7
Photo 8
Photo 9

Buy Now

Server Case UK Ltd

Server Case UK are the European authorised distributor and retailer for Logic Case. Server Case UK have thousands of chassis and components in stock for easy purchasing and shipping to any worldwide location.

Buy Logic Case SC-22470 from Server Case UK

Call: 0800 652 1649  |  Email: [email protected]  |  Website: www.servercase.co.uk

Specifications

Technical Details
Case Form Factor 2U Rackmount
Motherboard Compatibility Supports Micro ATX (9.6" x 9.6")
Drive Bays

External 5.25"

1
External 3.5" 0
Internal 3.5" 4
Internal 2.5" 0
Hotswap 3.5" 0
Hotswap 2.5" 0
Slim Optical 0
Slim FDD 0
Hot-Swap Backplane Not Applicable
Expansion Slots Full Height 0
Low Profile 4
Cooling 2 x 80mm front mounted fans direct airflow over the hard drives and motherboard. Hot swap fan frame and filter pad built in.
Power Supply Form Factor 1U Single PSU
Front Panel Connectors, Switches & Indicators Power Switch YES
Reset Switch YES
USB 2.0 2
USB 3.0 0
Serial 0
Indicators Power, LAN, and HDD LEDs
Colour Black
Material Steel
Dimensions & Weights
Packaging Single Box
Dimensions ( W x D x H ): 19" x 18.5" x 3.5" (483mm x 470mm x 88mm)
Weight 8.0 kg (Approx)
What's Included
  • 1 x Chassis
  • 1 x Accessory Box
