2U Short ATX Chassis - Low Profile PCI Card Support - 390mm Depth

2U Short ATX Chassis - Low Profile PCI Card Support - 390mm Depth

  • 2U Rackmount Form Factor
  • 390mm Chassis Depth
  • 482mm Chassis Width
  • 88mm Chassis Height
  • Standard ATX PSU Compatibility
  • Micro ATX M/B Form Factor
  • 2 Fixed Bays - External - 5.25"
  • 4 Fixed Bays - Internal - 3.5"
  • 4 Low Profile PCI Expansion Slots

Server Case are the European authorised distributor and retailer for Logic Case. Server Case have thousands of chassis and components in stock for easy purchasing and shipping to any worldwide location.

01283 576162 | [email protected]


BUY SC-24390 NOW shopping-icon
  • Reliable and fast service Reliable and fast service
  • Global distribution Global distribution
  • High quality & affordable High quality & affordable
  • Stock held in UK Stock held in UK
Technical Details
Case Form Factor 2U Rackmount
Motherboard Compatibility Mini-ITX, Micro ATX
Drive Bays

External 5.25"

External 3.5" 0
Internal 3.5" 4x Bays Total
Important Note: 4x Bays Usable with Mini ITX Motherboard Only
Important Note: 2x Bays Usable with Micro ATX Motherboard
Internal 2.5" 0
Hotswap 3.5" 0
Hotswap 2.5" 0
Slim Optical 0
Slim FDD 0
Hot-Swap Backplane Not Applicable
Expansion Slots Full Height 0
Low Profile 4
Cooling 2x 80mm Front Fans (Molex Input)
Power Supply Form Factor Standard ATX - 80mm Fan Only
Front Panel Connectors, Switches & Indicators Power Switch YES
Reset Switch YES
USB 2.0 1
USB 3.0 1
Serial 0
Indicators Power and HDD LEDs
Colour Black
Material SGCC
Dimensions & Weights
Packaging Single Box
Dimensions 482mm (W) X 390mm (D) X 88.8mm (H)
Weight 6kg (Approx)
What's Included
  • 1 x Chassis
  • 1 x Accessory Box
