2U Standard Chassis 9x 3.5" Internal HDD - 650mm Deep
Key Product Features:
- 2U Rackmount Form Factor
- 650mm Chassis Depth
- 430mm Chassis Width
- 88mm Chassis Height
- Standard ATX PSU Compatibility
- EEB (12" x 13") M/B Form Factor
- 9 Fixed Bays - Internal - 3.5"
Product Code/SKU: SC-H2-650
Buy Now
Server Case
Server Case are the European authorised distributor and retailer for Logic Case. Server Case have thousands of chassis and components in stock for easy purchasing and shipping to any worldwide location.
Buy Logic Case SC-H2-650 from Server Case UK
Call: 01283 576162 | Email: [email protected] | Website: www.servercase.co.uk
Specifications
| Technical Details | ||
|---|---|---|
| Case Form Factor | 2U Rackmount | |
| Motherboard Compatibility |
|
|
| Drive Bays |
External 5.25" |
0 |
| External 3.5" | 0 | |
| Internal 3.5" | 9 | |
| Internal 2.5" | 0 | |
| Hotswap 3.5" | 0 | |
| Hotswap 2.5" | 0 | |
| Slim Optical | 0 | |
| Slim FDD | 0 | |
| Hot-Swap Backplane | Not Applicable | |
| Expansion Slots | Full Height | 0 |
| Low Profile | 7 x PCI or PCI-E | |
| Cooling | 4 x 80mm front fans - Hot-Swap | |
| Power Supply Form Factor | Standard ATX (80mm Fans) or 2U Single PSU | |
| Front Panel Connectors, Switches & Indicators | Power Switch | YES |
| Reset Switch | YES | |
| USB 2.0 | 2 | |
| USB 3.0 | 0 | |
| Serial | 0 | |
| Indicators | Power, LAN, and HDD LEDs | |
| Colour | Black | |
| Material | SGCC | |
| Dimensions & Weights | ||
| Packaging | Single Box | |
| Dimensions | (DxWxH): 650mm x 430mm x 89mm | |
| Weight | 11.55 kg (Approx) | |
| What's Included | ||
|
||
