4U GPU Enhanced Standard Chassis 4x 3.5" HDD + 6x 5.25" Bays - 8x Full Height Slots for 4x Double Width GPU
Key Product Features:
- 4U Rackmount Form Factor
- 570mm Chassis Depth
- 483mm Chassis Width
- 176mm Chassis Height
- Standard ATX PSU Compatibility
- CEB (12" x 10.5") M/B Form Factor
- 6 Fixed Bays - External - 5.25"
- 4 Fixed Bays - Internal - 3.5"
- 1 Slim ODD
- 8 Full Height PCI Expansion Slots
Product Code/SKU: SC-4550MG-2
Buy Now
Server Case UK Ltd
Server Case UK are the European authorised distributor and retailer for Logic Case. Server Case UK have thousands of chassis and components in stock for easy purchasing and shipping to any worldwide location.
Buy Logic Case SC-4550MG-2 from Server Case UK
Call: 0800 652 1649 | Email: [email protected] | Website: www.servercase.co.uk
Specifications
| Technical Details | ||
|---|---|---|
| Case Form Factor | 4U Rackmount | |
| Motherboard Compatibility | Mini-ITX, Micro ATX, Standard ATX, Extended ATX | |
| Drive Bays |
External 5.25" |
6 |
| External 3.5" | 0 | |
| Internal 3.5" | 4 | |
| Internal 2.5" | 0 | |
| Hotswap 3.5" | 0 | |
| Hotswap 2.5" | 0 | |
| Slim Optical | 1 | |
| Slim FDD | 0 | |
| Hot-Swap Backplane | Not Applicable | |
| Expansion Slots | Full Height | 8 |
| Low Profile | 0 | |
| Cooling | 1x Front 80mm 2x Rear 60mm |
|
| Power Supply Form Factor | Single ATX PSU (Redundant ATX Not Supported) | |
| Front Panel Connectors, Switches & Indicators | Power Switch | YES |
| Reset Switch | YES | |
| USB 2.0 | 2 | |
| USB 3.0 | 0 | |
| Serial | 0 | |
| Indicators | Power, LAN, and HDD LEDs | |
| Colour | Silver | |
| Material | SGCC | |
| Dimensions & Weights | ||
| Packaging | Single Box | |
| Dimensions | ( W x D x H ): 19" x 15.74" x 7" (483mm x 570mm x 176mm) | |
| Weight | 12kg (Approx) | |
| What's Included | ||
|
||
