4U GPU Enhanced Standard Chassis 4x 3.5" HDD + 6x 5.25" Bays - 8x Full Height Slots for 4x Double Width GPU

Key Product Features:

  • 4U Rackmount Form Factor
  • 570mm Chassis Depth
  • 483mm Chassis Width
  • 176mm Chassis Height
  • Standard ATX PSU Compatibility
  • CEB (12" x 10.5") M/B Form Factor
  • 6 Fixed Bays - External - 5.25"
  • 4 Fixed Bays - Internal - 3.5"
  • 1 Slim ODD
  • 8 Full Height PCI Expansion Slots
Product Code/SKU: SC-4550MG-2
4U GPU Enhanced Standard Chassis 4x 3.5
Photo 1
Photo 2
Photo 3
Photo 4
Photo 5
Photo 6
Photo 7

Buy Now

Server Case

Server Case are the European authorised distributor and retailer for Logic Case. Server Case have thousands of chassis and components in stock for easy purchasing and shipping to any worldwide location.

Buy Logic Case SC-4550MG-2 from Server Case UK

Call: 01283 576162  |  Email: [email protected]  |  Website: www.servercase.co.uk

Specifications

Technical Details
Case Form Factor 4U Rackmount
Motherboard Compatibility Mini-ITX, Micro ATX, Standard ATX, Extended ATX
Drive Bays

External 5.25"

6
External 3.5" 0
Internal 3.5" 4
Internal 2.5" 0
Hotswap 3.5" 0
Hotswap 2.5" 0
Slim Optical 1
Slim FDD 0
Hot-Swap Backplane Not Applicable
Expansion Slots Full Height 8
Low Profile 0
Cooling 1x Front 80mm
2x Rear 60mm
Power Supply Form Factor Single ATX PSU (Redundant ATX Not Supported)
Front Panel Connectors, Switches & Indicators Power Switch YES
Reset Switch YES
USB 2.0 2
USB 3.0 0
Serial 0
Indicators Power, LAN, and HDD LEDs
Colour Silver
Material SGCC
Dimensions & Weights
Packaging Single Box
Dimensions ( W x D x H ): 19" x 15.74" x 7" (483mm x 570mm x 176mm)
Weight 12kg (Approx)
What's Included
  • 1 x Chassis
  • 1 x Accessory Box
